PVC Curtain
Product Description
Product introduction:
PVC door curtain considerably reduces the problem of draughts, spray, welding flash, noise and dust. Clear PVC door curtain provides good visibility and allows an easy passage to and from your working area. In food preparation areas and where forklift truck access is required PVC door curtain can help maintain room temperature as well as keeping out dust and insects. PVC door curtain is easy to fit and, once installed, the strips can be easily removed or replaced if required.
Key Features:
Frosted surface( Surface is crude like ground glass), reduces draught, noise and dust. Easy to install, keeps out insects and maintains temperature.
Technical data:
| Frosted PVC Strip Curtain | ||
| Applications | Pedestrian doorways, loading bays, cold stores, welding bays, conveyors and food preparation areas. | |
| Standard Size | 200mm X 2mm | |
| 200mm X 3mm | ||
| 300mm X 2mm | ||
| 300mm X 3mm | ||
| 300mm X 4mm | ||
| 400mm X 3mm | ||
| 400mm X 4mm | ||
| Length | 50m or as your requirements | |
| Color | translucent | |
| Finish | Smooth and Double Ribbed | |
| Packaging | Pvc shrink film for each roll, then be piled on pallet. Pvc shrink film and carton box for each roll, then be piled on pallet | |
| Certification | Reach / Rohs | |
| Item | Unit | Index |
| Light Transmittance | %(thickness 2.5mm) | ≥ 80 |
| Tensile Strength | Mpa | ≥ 20 |
| Elongation at break | % | ≥ 200 |
| Heat Treatment Dimension | %(80°C 12 hour) | Crosswise ≤ 1.2 Lengthwise ≤ 2.0 |
| Bending Property under Low Temperature | No crack under -20°C | |
| Withstanding Voltage | No arcing over under 10KVmin | |
OEM & customized size are agreed. Packing in rolls and pallets.
