Silicone Rubber Sheet

Inquire Now Next Product

Product Description

Product introduction:

Silicone rubber sheet have comparatively low mechanical properties, tensile strength, elongation and tear strength, however silicone rubber sheet keep constant even at high temperatures but should not be used with high pressure steam. Silicone rubber sheet resistance to oils and hydrocarbon products is fairly limited and similar to that of chloroprene rubbers. Reasonable resistance to a whole range of general chemical products, but acids, alkalis, esters and ketone should be avoided. Silicone rubber sheet has excellent resistance to heat(dry air),at +200℃ intermittent. Silicone rubber sheet remains flexible at low temperatures of -70℃ and is also resistant to ultra-violent light, ozone and weathering. And silicone rubber sheet has good electrical insulation properties.

Features:

1) Excellent resistance to heat (dry air), at +200º C continuous and +220º C intermittent.Remains flexible at low temperatures of -50ºC.

2) Resistant to ultra-violet light, ozone and weathering

3) Good electrical insulation properties

4) Keep constant even at high temperatures

Technical data:

Quality	Specific Gravity	Tensile Strength	Elongation	Hardness	Temperature
Silicone Rubber	1.3 g/cm3	7Mpa	350%	40+/-5 shore A	-60/+220℃
Silicone Rubber	1.15g/cm3	7Mpa	350%	40+/-5 shore A	-60/+220℃
Application	Silicone rubber sheeting is preferred choice of the medical, pharmaceutical and food processing industries. It also maintains its stability in extreme environments, and its operative properties remain invariable over a wide temperature range, used in a large number of industrial applications in the automotive, electronics and lighting sectors, amongst others.
ITEM NO.	TSI-S			Resistance
Thickness	1.0mm 2.0mm 3.0mm	4.0mm 6.0mm 8.0mm		Oil	Good
Width	1000mm 1200mm			Aging	Good
Length	5m / 10m			Fuel	Not Recommended
Colour	Red / Transparent / Black			Acidity	Good

Silicone Rubber Sheet

OEM & customized size are agreed. Packing in rolls and pallets.
